INFRASTRUCTURE:
-
The Department has sufficient number of well-furnished, well ventilated, spacious class rooms with technology enabled to facilitate active and better learning. They are also ideal for organizing small seminars and workshops where the audio-visual facilities are available.
-
The Department of Mechanical Engineering has over 10 laboratories including thermal engineering, heat-transfer, Mechanical Engineering, Manufacturing Technology, Metrology, Industrial Engineering, Mechatronics, etc. Modern computing facilities are available for students at the Computer Aided Design and Computer Aided Manufacturing Laboratories.
-
All the laboratories are provided with the state of art equipment. Laboratories are well equipped, and well maintained not only for carrying out curriculum-oriented lab practical but also to carry out research activities.
-
Department has a separate Library with an area of 820 square feet which has 400+ titles, 15337 volumes and 420 UG and PG students project reports.
-
Department has separate seminal hall to conduct conferences, workshops and symposia for students and faculty. It has a seating capacity of 200 and is fully air conditioned. It is equipped with LCD projector, LCD screen, white board and public addressing system.
| S.No | Name of the Laborarory | Name of the Important Equipment | Area in Sq.Mts |
|---|---|---|---|
| 1 | Engineering workshop | 1. Carpentry Bench Vices, Handsaws, Metal jackplanes. 2. Fitting Bench Vices, Hacksaw frames, Files, Piller type Drilling machine. 3. Stakes, Snipers, Mallets, Power press. 4. Standard wire gauges, Testers, Screw drivers, Cutting Pliers, Lamp holders, wires. 5. Blast furnaces, swage block, anvil, sledge hammer, tongs. |
414.61 |
| 2 | Mechanical Engineering Lab-I | 1. Redwood Viscometers –I & II, 2. Saybolt’s Apparatus, 3. Pensky Martins flash point Apparatus, 4. Pressure gauge, 5. Carbon Residue test, 6. Valve Timing Diagram of 4-Stroke Diesel Engine, 7. Port Timing Diagram of 2-Stroke Petrol Engine, 8. Fly Wheels, 9. Compound Pendulas, 10. Clevelands open cup Apparatus and Torsional Oslometers. |
75.92 |
| 3 | Manufacturing Technology Lab-I. | 1. Machine Lathe-19 No's 2. HMT Lathe- 1 No's 3. Capstan Lathe-1 No's 4. Milling Machine-1No's 5. Arc Welding Equipment 6. Foundry Equipment 7. Foundry Tools 8. Hydraulic Power Hacksaw-2No's 9. Shaping Machine-1No's. 10. Planer Machine-1No's. |
367.36 |
| 4 | Strength of materials Lab | 1. Universal materials testing system 2. Rockwell hardness tester 3. Brinell and Vickers hardness tester 4. Impact testing machine 5. Torsion testing machine 6. Universal testing machine |
136.33 |
| 5 | Mechanical Engineering Lab-II. | 1. Single cylinder 6 HP Diesel Engine With Belt Brake drum 2. Single Cylinder 5 HP DieselEngines -2 (Coupled with Hydraulic Brake Dynometer/ DC Generator) 3. Single Cylinder6 HP Diesel Engine With Rope Brake dynometer 4. Twin Cylinder 10 HP Diesel Engine with Hydraulic Brake Dynometer 5. Four Cylinder 10 HP Petrol Engine Coupled with Hydraulic brake Dynometer 6. Single Cylinder 3HP (Petrol/ kerosen) Engine with Rope Brake drum 7. Two Stage Reciprocating Air Compressor 8. Single Cylinder Two Stroke 4 HP Diesel Engine 9. Motorised Gyroscope (with 5000rpm) 10. Static & Dynamic balance (with 6000rpm) 11. Four HP Motor With Water Pump Set 12. I C Engine Components 13. Computer BasedSingle Cylinder 4 Stroke VCR Multi Fuel Engine 14. Computer Based Multi Cylinder Petrol Engine Test 15. Six Gas Analyzer EPM1602 for Measuring CO, HC, CO2, O2, NO & SO2, with standard accessories, software & built in 24 column Dot Matrix Printer 16. Diesel Smoke Meter with standard accessories, software & built in 24 column Dot Matrix Printer |
339.23 |
| 6 | Manufacturing Technology Lab-II. | 1. Universal Milling machine 2. Shaping machine 3. Surface grinding machine 4. Surface roughness tester 5. Slotting machine 6. Sieve shaker 7. All cut machine 8.Tool and Cutter Grinder 9. All geared bench Drilling machine 10. Rapid moisture teller 11. Clay content testing machine 12. Universal compression strength machine 13. Hardness tester 14. Sand rammers 15. Weighing machine(Mechanical and Electrical ) |
392.78 |
| 7 | Metrology and Mechatronics Lab. | 1.Vernier calipers-11No's 2. Slip gauge set-2No's 3. C.I Surface plate 4. Angle Plate-2No's 5. Granite surface plate 6. Dial gauge-4No's 7. Outside micro meter-4No's 8. Compact Tool makers Micro Scope-2No's 9. Thread ring gauge set-1No's 10. Optical bevel protractor-2No's 11. Five channel digital strain gauge meter-2No's 12. Indicating micro meter-1No's 13. Surface roughness indicators-2No's 14. Electrons compactors - 2No's 15. Profile projectors-2No's, s |
75.15 |
| 8 | Industrial Engineering Lab. | 1. Bicycle Ergo meter, 2. Tread mill, 3. Electric toasters, 4. B.P Apparatus, 5. Weight Machine, 6.Vernier Callipers -2 No’s, 7. Plain plug Gauges, 8. Stop watches-13 No's, 9. Stethoscopes -3No's | 93.09 |
| 9 | Fluid Mechanics Lab | 1. Pelton turbine test rig-1No’s 2. Pipe friction apparatus-1No’s 3. Bernaullies apparatus-1No’s 4. Notches ( V-Rectangular, trapezoidal) -1No’s 5. Venturi meter-1No’s 6. Orifice meter-1No’s 7. Pitot Tube-1No’s 8. Reciprocating Pump test rig-1No’s 9. centrifugal pump test rig-1No’s 10. Impact of jet on Inclined, flat and curved vane-1No’s |
104.04 |
| 10 | Heat and Mass Transfer Lab | 1. Thermal Conductivity of metal Bar Apparatus -1No’s 2. Composit wall Apparatus -1No’s 3. Pin Fin Apparatus -1 No’s 4. Natural convection on vertical bar Apparatus-1 No’s 5. Stefan Boltzman's Apparatus-1 No’s 6. Emissivity measurement Apparatus-1 No’s 7. Parallel and Counter flow Apparatus-1 No’s 8. Drop and Film Wise Condensation phenomenon-1 No’s 9. Forced Convection Apparatus-1 No’s 10. Two Phase heat Transfer Apparatus-1 No’s 12. Refrigeration test rig -1 No’s 13. Air Conditioning Text Rig-1 No’s |
75.56 |
| 11 | CAD Lab | 1.Computer systems :88 No's 2. UPS : 6KVA UPS 3. Auto CAD2004 : 4 user 4. ANSYS 12: 1user 5. Solid works:100 user 6. Pro-E Wild Fire 3 - 5 users 7. CATIA V5- 5 users |
140.27 |
| 12 | CAM Lab | 1.Computer systems - 2 No's 2. CNC Turning -1 No’s 3. CNC Vertical Milling -1 No’s 4. Hetero fitted Turning- 1 No’s 5.CMAS Soft - 5 users. |
15.41 |
| S.No | Name of the Laborarory | Name of the Important Equipment | Area in Sq.Mts | |
|---|---|---|---|---|
| 1 | Centre for Metal Matrix Composite | 1. Rotary Fatigue testing machine 2. Electrical resistance furnace |
Utilized by UG/PG Students for conducting Fatigue tests and the fabrication of composites using liquid metallurgy route. | 14.26 |
| 2 | Center for collaborative product development | 1. Coordinate measuring machine 2. 3D Printer 3. CAD Station |
Utilized by UG/PG Students for measuring the co-ordinates of complex profiles, fabrication of parts using fused deposition modelling and Design the models. | 35.92 |
| 3 | Development of multilayer thin film sensor for practical monitoring of weld stress | 1. Thermo Mechanical Strain gauge tester. | Utilized by UG/PG Students for measuring of strain in thermal environment. | 15.33 |
| 4 | Nanotechnology Research Centre | 1. UV- Visible spectroscopy 2. Fluorescence 3. Double distillation 4. Rotary evaporator 5. Ultra centrifuge 6. Sonicator 7. Microfluidics module |
Utilized by UG/PG Students for doing their Nano Research. | 76.65 |
| 5 | APPSC (Dassault Systems Lab) | 1. Laptops :36 No's, 2. 3-D Experiences Soft Ware-Provided by Dassault Systems. |
Utilized by UG/PG Students are Trained the 3-D Experiences Software. | 64.62 |
